Multi-Tier
Technology Architecture
A granular blueprint of the enterprise network integration, edge processing, sovereign cryptographic trust, enterprise AI/mobile gateways, and high-availability cloud hosting tiers that power RAPIDO INFRATEL LLP products.
Architectural orchestration of enterprise network backbones, edge aggregation POPs, and high-availability routing rings.
Tier 1: Enterprise Digital Network Interface & Integration Bus
Software and hardware interface layer abstracting underlying high-capacity enterprise digital backbone networks and data pipelines.
- Network Interconnect: Direct Layer-2/Layer-3 enterprise network peering
- Multi-gigabit ring topology interfaces with automated failover
- Throughput Capacity: Multi-terabit routing interface with sub-millisecond queuing
- Resilience Bus: Automated ring protection failover coordination
Tier 2: Edge Aggregation & Cloud POP Facilities
Strategically sited Point of Presence (POP) software gateways with redundant DC power, environmental monitoring, and enterprise-grade edge routing nodes.
- Routing Protocol: BGP Anycast routing with sub-10ms localized packet steering
- Power Backup: N+1 SMPS Rectifiers with Lithium Ferro Phosphate (LFP) banks
- Ring Topology: Dual-parented ring protection with sub-50ms failover orchestration
- Edge Compute: Containerized edge micro-clusters for localized civic caching
Tier 3: Sovereign Trust & Digital Public Infrastructure
Hardware-isolated cryptographic trust perimeter integrating national identity and credential issuance stacks with complete audit trails.
- Authentication: AUA / KUA compliant Aadhaar OTP and biometric APIs
- Document Vault: DigiLocker Push/Pull integration with tamper-proof SHA-256 digests
- PKI Security: FIPS 140-2 Level 3 compliant Hardware Security Modules (HSMs)
- Zero-Trust: WireGuard / IPsec encrypted inter-facility transit tunnels
Tier 4: Municipal GIS & Unified Civic API Mesh
Cloud-native microservices bus orchestrating spatial cadastre databases, real-time IoT sensory telemetry, and single-window citizen transactions.
- Spatial Engine: OGC-compliant PostGIS spatial indexing & vector tile layers
- API Gateway: Open API 3.0 compliant high-throughput microservices mesh
- Telemetric Ingestion: MQTT / Kafka message brokers handling 100k+ events/sec
- Localization: Bhashini Indian language NLP translation microservices
Tier 5: Enterprise AI, Mobile Gateways & Rapido Hosting
High-availability enterprise datacenter infrastructure powering AI inference models, mobile app backend services (iOS & Android), and premier domain resolution.
- Hosting: Sovereign cloud servers, managed VPS & Anycast DNS resolution
- AI Architecture: Containerized inference pipelines & Bhashini voice synthesis
- Mobile Mesh: Low-latency GraphQL and WebSocket citizen-facing gateways
- SLA Standard: 99.999% high-availability datacenter cluster resilience
Open-Access Community Wi-Fi Mesh Stack
Network-Neutral Edge Aggregation & Open-Standard Civic Protocol Interoperability
Dual-band 802.11ax (Wi-Fi 6) access points installed across public plazas, transit hubs, and civic nodes with seamless captive portal handshakes.
Decentralized session routing, bandwidth allocation, quality-of-service (QoS) prioritization, and privacy-preserving token verification.
Interoperable user discovery, instant KYC authorization, and seamless micro-payments via UPI for sachet civic connectivity.
Sovereign Anycast Edge Routing & Latency Monitor
Real-time telemetry and sub-millisecond edge resolution across Indian and Global Anycast nodes.
Solutions Architecture Governance & Multi-Tier Review
Every systems design undergoes rigorous cross-functional peer reviews by our Solutions Architecture Committee in Ahmedabad. We enforce strict architectural separation between enterprise network interfaces, microservice pipelines, and cryptographic enclaves to guarantee multi-decade operational durability.
- Deterministic data bus latency evaluation under peak transactional load
- Zero-trust cryptographic isolation across all external API boundaries
- Automated regression and chaos verification before production rollout
Need a Customized Blueprint for Your Municipal, Enterprise or Cloud Network?
Our solutions architecture team prepares detailed Architecture Blueprints, Data Flow Topology Maps, and Systems Specifications.
Consult Solutions Architecture Committee
